REPRESENTATIVE EXCERPT — FOR REFERENCE ONLY (from p.89)
On turning the steering wheel, the cam causes the piston to enter the body and part of the liquid in chamber C is evacuated, via the valve towards the governor. The piston compresses the spring and the barrel finally abut against the body. The pressure acting on the piston is always that supplied by the governor. Centring position :
