REPRESENTATIVE EXCERPT — FOR REFERENCE ONLY (from p.83)
The power assistance piston is in disequilibrium, the steering rack moves, the steering rack pinion is drawn along by this movement causing a transmitted movement of the valve, this opens the pressure release in chamber B until the pressure P/2 is re-established and the state of equilibrium restored. '
