REPRESENTATIVE EXCERPT — FOR REFERENCE ONLY (from p.83)
- A very slight rotating movement between the control shaft and the steering rack pinion causes a transmitted movement of the roller valve. - The regulation of pressure P/2 in chamber B is mechanical and takes place at the level of the steering rack, the steering rack pinion and the valve. ' Examples : 1/ Pressure-in chamber B is > P/2
