Citroën Hydraulics Course Notes — 844
SECTION OVERVIEW

Diravi steering

Diravi steering, page 79 of 91 — 844 Hydraulics Course Notes
REPRESENTATIVE EXCERPT — FOR REFERENCE ONLY (from p.85)

- The stiffening of the steering is obtained by the exertion of a mechanical force on the steering control shaft and is completely of the power assistance. ' - The control shaft is geared to a heart shaped cam, on which a piston with a cam follower, applies a torque varying with the pressure supplied by the steering governor and the rotation angle of the control shaft.
