REPRESENTATIVE EXCERPT — FOR REFERENCE ONLY (from p.85)
- When the steering wheel is turned, the point of contact of the cam follower and the cam itself, due to its shape, is no longer along the axis O and O'. The force of the piston therefore exerts a torque in relation to the O', which acts against the turning movement caused by the driver. - The steering becomes stiffer as the speed of the vehicle increases because the force exerted by the piston increases with the pressure supplied by the steering '
