Citroën Registry
844 Hydraulics Course Notes — Page 48
Citroën Hydraulics Course Notes — 844
SECTION OVERVIEW

Hydraulic gear selector

Hydraulic gear selector, page 48 of 91 — 844 Hydraulics Course Notes
REPRESENTATIVE EXCERPT — FOR REFERENCE ONLY (from p.47)

- In the latter position of the slide-valve, the vehicles clutch is engaged, which allows ; - the freeing-off of the motor and starting on the handle - valve clearance adjustments, b) Rise of pressure - de-clutching : ( manual clutch control slide-valve in its normal position ) - Before the hydraulic selector slide-valve is supplied with fluid under pressure, the position of the automatic clutch control slide-valve is such that :
