REPRESENTATIVE EXCERPT — FOR REFERENCE ONLY (from p.43)
. Preponderance of front braking : Pressure rises in the front brake circuit first. When this pressure is sufficient to compress the spring R2 the rear brakes are fed. This distribution of braking pressure is of the load in the car. The difference is maintained no matter what the pressure is on the pedal.
