REPRESENTATIVE EXCERPT — FOR REFERENCE ONLY (from p.163)
Idling air correction jet Ref. No (©) By-pass jet 60 Ref. No. By-pass air jet 90 Ref. No. ©) Accelerator pump injector 60 Ref. No. @® Econostat - Petrol jet 145 Ref. No. 6) Air jet 80 Ref. No. ® Polyamide fuel float Ref. No. 12 42g Ball type needle valve Ref. No. @ 1.8 Positive opening of Ist choke butterfly 1.25 + 0.05 mm Opening of the strangler flap with 400 mm Mg (530 mb) +2 = OS tm Mixture control screw Ref. No.
Vehicle Application: Citroën CX 20 · CX 22 · CX 25 · September 1988
