REPRESENTATIVE EXCERPT — FOR REFERENCE ONLY (from p.85)
- For every position of the steering wheel, the wheels are locked at a definite angle. This is an important safety feature. The lock cannot be influenced by, for example : - unequal braking on the right and left wheels - by a burst tyre, a tyre hitting a large obstacle or on yielding ground, a deep puddle, ... Il - PROGRESSIVE STIFFENING OF STEERING AS SPEED INCREASES
