REPRESENTATIVE EXCERPT — FOR REFERENCE ONLY (from p.89)
The more the steering wheel is turned, the more compressed the spring becomes; the flow speed through the calibrated hole and therefore the speed of has a certain value when begins and moves towards zero as the steering returns to the straight ahead position.
