Citroën Hydraulics Course Notes — 844
SECTION OVERVIEW

Diravi steering

Diravi steering, page 71 of 91 — 844 Hydraulics Course Notes
REPRESENTATIVE EXCERPT — FOR REFERENCE ONLY (from p.70)

Straight line position : : The force of the piston F acts in the hollow of the cam and tends to keep the vehicle in a straight line. When turning: The point of contact of the cam follower situated outside the axis O and O', exerts a torque which acts against the turning movement caused by the driver, therefore : hardening.
