Citroën Hydraulics Course Notes — 844
SECTION OVERVIEW

Centrifugal regulator

Centrifugal regulator, page 50 of 91 — 844 Hydraulics Course Notes
REPRESENTATIVE EXCERPT — FOR REFERENCE ONLY (from p.52)

When Ist or 2nd gears are being engaged, the ball, lifted by a shoulder on the ball control rod pushes the slide-valve which blocks the fluid passage. As long as and engagement do not take place the selector fork shaft (1st and 2nd ) and the ball control rod remain in this intermediate position, and stop the escape of fluid from clutch slave cylinder.
