Dismantling – Rear Axle (Old), page 98 of 260 — Twelve & Fifteen Repair Manual — Text
Page ↔ Forum
Start a discussion
Find related SP-6
light15 · p.98
EXTRACTED TEXT — FOR REFERENCE ONLY

OPERATION 130 (Continued) DISMANTLING, CHECKING AND RE-ASSEMBLING OF REAR AXLE (01 under nuts of sheath brackets and tighten to a tension of 2 (143 foot pounds). Tighten nuts fixing brake back plates to a tension of 2 (143 foot pounds). Turn back tabs. (b) Position the four brake shoes. Use gauge 2103-T (see Drawing 80). FIT HUBS AND BRAKE DRUMS (See Drawing 70)
