814 Repair Manual — Volume I — Page 400
Citroën Repair Manual N°814, Volume I
SECTION OVERVIEW

Headlamps / Levelling from Sept '67

Headlamps / Levelling from Sept '67, page 400 of 454 — 814 Repair Manual — Volume I
REPRESENTATIVE EXCERPT — FOR REFERENCE ONLY (from p.398)

c) Tighten screw (2) holding clamp on anti-roll bar (4). » Position the rear control torsion rod (6) on the D, 54-3 rear anti-roll bar (5). (see diagram on page | for part markings) a) Remove panel protecting rear corrector control. (Inside the rear boot) b) Lateral positioning : Place cable hook lever «k» in of hole for passage of cable in rear unit. Without affecting the functioning, the lever «k » may be offset up to 2 mm to left of the of the hole.
