814 Repair Manual — Volume I — Page 204
Citroën Repair Manual N°814, Volume I
SECTION OVERVIEW

Hydraulic system / Source and reserve of pressure

Hydraulic system / Source and reserve of pressure, page 204 of 454 — 814 Repair Manual — Volume I
REPRESENTATIVE EXCERPT — FOR REFERENCE ONLY (from p.209)

a) Stop by means of plugs : - Opening «b» of the rear suspension feed pipe - End-piece «c» of the three way union connect the front suspension feed pipe to the security valve. Tighten the bleed screw Put height control lever in normal running position Allow the engine to turn until front of vehicle rises and cut out occurs wait 10 seconds for the pressure to stabilize then switch off.
