Citroën Hydraulics Course Notes — 844
SECTION OVERVIEW

Clutch re-engagement control

Clutch re-engagement control, page 58 of 91 — 844 Hydraulics Course Notes
REPRESENTATIVE EXCERPT — FOR REFERENCE ONLY (from p.57)

While the pressure is rising in the slave cylinder, the fluid pushes on the throttle-closing piston. The entry of fluid to the piston is slowed by making it pass a ball with 3 grooves on its seating, the fluid passing by the grooves. The restriction of the fluid is necessary to avoid « hammering » in the hydraulic circuit, and above all to prevent the throttle from being closed too quickly.
