REPRESENTATIVE EXCERPT — FOR REFERENCE ONLY (from p.30)
1. The Height Corrector a) Description : It is a distributor block ( 3-way tap ) which, depending on the position of the slide-valve : - connects the services ( suspension cylinders ) to the inlet ( HP supply ) - connects the services ( suspension cylinders ) to the outlet ( Reservoir ) - isolates both the inlet and outlet from the services ( slide-valve central ).
