Dismantling – Rear Axle (Old), page 94 of 260 — Twelve & Fifteen Repair Manual — Text
Page ↔ Forum
Start a discussion
Find related SP-6
light15 · p.94
EXTRACTED TEXT — FOR REFERENCE ONLY

OPERATION 130 DISMANTLING, CHECKING, AND RE-ASSEMBLING OF REAR AXLE (OLD MOL DISMANTLING OF REAR AXLE (See Drawings 70 and 72). Place assembly on a suitable stand. Remove Lockheed brake pipes. Remove hubs and brake drums (3). Remove brake back plates (4). (Clean brake cable sheaths with a wire brush and lubricate them to ease their sliding in the guides). Remove tie-rod (1). (First remove nut (32) at tubular end to prevent rod from turning). :
