814 Repair Manual — Volume I — Page 242

a = m3- 8,675 mm c) If the measure «a» is not equal to 14+0,25 mm operate screw (3) 7. Release the pressure by loosening the test bench bleed screw «cn, 8. Refit the pedal panel, the pedal and the trimming. 9. Remove the tube connecting the pump to the brake pedal gear feed pipe. Remove the sealing plug from the four way union (2) and connect pipe (1) to the union ( 2). Fit the pipe assembly fixing lug (4).
