814 Repair Manual — Volume I — Page 163

Citroën Repair Manual N°814, Volume I
SECTION OVERVIEW

Gearbox / 4-speed

Gearbox / 4-speed, page 163 of 454 — 814 Repair Manual — Volume I
REPRESENTATIVE EXCERPT — FOR REFERENCE ONLY (from p.168)

c) Check the position of third gear : Engage 3rd gear, the sliding pinion in contact with the 3rd gear loose pinion Measure and note the fork shaft projection. For example : 1.3 mm d) Check the position ot fourth gear : Engage 4th gear, the sliding pinion in contact with the 4th gear loose pinion. Again check the fork shaft projection. For example : 23,9mm.
