Figure 2 represents the advance curve of the preceding distributor assembled on the engine. The curves in figure l and figure 2 are identical but displaced vertically from the static ignition value; moreover turning the distributor also displaces the advance curve vertically : the advance curve rises when the distributor is turned in the advance- increase direction, and
