Citroën Registry
814 Repair Manual — Volume I — Page 113
Citroën Repair Manual N°814, Volume I
SECTION OVERVIEW

Using Bosch tester

Using Bosch tester, page 113 of 454 — 814 Repair Manual — Volume I
REPRESENTATIVE EXCERPT — FOR REFERENCE ONLY (from p.107)

- VOLTMETER - The needle should move towards the max. end of the scale then oscillate about an reading. The variation between the two average readings must not be more than two divisions (Read on the upper scale-voltmeter) between positions «Distrib. Contact |» and «Contact II». If the variation exceeds two divisions ( upper scale-voltmeter ) - The triggering contacts are defective. Replace the contact cassette.
