REPRESENTATIVE EXCERPT — FOR REFERENCE ONLY (from p.108)
- From the voltage regulator (a) - From the injection system harness (b) - From the battery (c) See illustrations on page 17. - From the electrical fuel pump (d) - From the car chassis( e) Check the tightness of the bolts and pull gently on the leads to ensure that they are properly secured to their terminals.
