Citroën Repair Manual N°814, Volume I
SECTION OVERVIEW

Using Citroen tester

Using Citroen tester, page 80 of 454 — 814 Repair Manual — Volume I
REPRESENTATIVE EXCERPT — FOR REFERENCE ONLY (from p.81)

Put the intermediary wiring (5) into position between the connector (6) of the triggering contact holder and the vehicle harness. Ensure that the inhibition cham «a» on the 3-way connectors (3) and (4) correspond. - Run the engine at 1500 rpm approx. - Connect the voltmeter. The «—» on plug (2) (black ) The «+» in turn on plugs (1) (red).
