814 Repair Manual — Volume I — Page 49

* 70 for man and Borg Warner - 75 for - Strangler flap setting : With the strangler flap closed, and the in idling position, the distance between the point of the screw (1) (Throttle stop screw) and the lug (2) on the primary choke, must be : a = 3.8 mm. If necessary bend the lug (2) to obtain this distance.
