EXTRACTED TEXT — FOR REFERENCE ONLY
For the and its special parts apply direct to Wessrs, Solex or their accredited agents. Screw, hex. hd, 4 7,5 long Fixing control rod (R. ITT) Screw, g 19 long Fixing front and rear brackets of air silencer on manifold (R. III) Screw, § 22,5 long Fixing inlet pipe to silencer (R. ETE) Screw. hex. hd. 7 12,5 long Fixing bracket 587399 (R.IIL) Screw, hex, hd. 7 15 long Fixing pedal to pedal shaft (RIZE)
